Interface

1 * 10/100/1000M RJ45 LAN/POE port(POE power supply)

Antenna

5 * built-in high gain antenna

Button

RESET Button

Power Supply

48V standard POE or external DC 12V/2A power supply

LED

Blue: network normally

Red: network anomaly

Mounting

Ceiling /Wall Mounting (Kits included)

Memory

256MB

FLASH

128MB

Forwarding rate

1000Mbps

Gateway

Dynamic acquisition

Connected devices

Modifying a Device Name

Speed limit

Blacklist

Signal conditioning

Low、Middle、High

Frequency

2.4 GHz and 5 GHz

Signal Rate

574Mbps at 2.4GHz

2402Mbps at 5GHz

Wireless Standards

IEEE802.11ax

IEEE802.11ac

IEEE802.11n

wireless network

Dual frequency integration

WiFi name (SSID)

Encryption
Hide Network Name

Network Mode：

2.4G- 802.11b、802.11b/g、802.11b/g/n

5G- 802.11a、802.11a/n、802.11a/n/ac

Channel bandwidth：

2.4G-automatic、20M、40M

5G-automatic、20M、40M、80M

Wireless channel

Router Information

Router Information

Internal network information

Indicator light

LED switch

Initialization

Restore Factory

Manage Passwords

New Password

Confirm Password

Time Setting

System time acquisition method：NTP (Online)、Manual configuration

Firmware Upgrade

Manual Upgrade

Online Upgrade

Dimensions

194 * 194 * 45.5mm

Environment

Operating Temperature : 0℃ ~ 40℃

Operating Humidity : 10% ~ 90% RH non condensing

Storage Temperature : -20℃ ~ 70℃

Storage Humidity : 5% ~ 90% RH non condensing
